In order to make the information more intuitive and easy-to-read, I sorted it out according to the points of “core positioning, structural configuration, operating performance, and adaptation guarantee”, maintaining a plain and professional expression, and avoiding AI-based terminology: Special conveying line for refrigerators: heavy-duty and stable transfer equipment for home appliances
1. Core positioning
Specially customized for refrigerator production, focusing on the core requirements of “heavy load bearing, flexible adaptation, and smooth transfer” in view of the characteristics of heavy box, diverse models, and complex assembly processes. Covering the entire process of refrigerator liner forming, refrigeration system assembly, box foaming, door body installation, performance testing to finished product packaging, logistics transportation
2. Structural configuration
Main frame: Made of thick steel and equipped with wear-resistant and heavy-duty conveyor belts. It has a rated load bearing of 2 tons and a peak load bearing of 2.5 tons. It firmly supports refrigerator boxes of different volumes. Track specifications: Width 800-1200mm can be flexibly adjusted, compatible with single door, double door, triple door, opposite door, cross door and other structures, suitable for the mainstream volume of 100-600L, supporting mixed line production of household/commercial refrigerators Protective design: The surface of the tooling plate is non-slip and wear-resistant, and flexible anti-collision strips are installed on the edges to avoid scratching and bumping of the refrigerator shell; the entire line is equipped with anti-deviation guide rails, and the heavy-duty sections are strengthened and reinforced
3. Operating performance
Speed control: Adopt high-power gear reduction motor + frequency conversion speed regulation, 15 m/min in the box transfer section (to ensure flow efficiency), and 6 m/min in the assembly and inspection section (to adapt to precision processes) Positioning accuracy: Key workstations are equipped with pneumatically driven jacking positioning tables, with mechanical positioning accuracy of ±0.5mm, ensuring the accuracy of door body docking, pipeline installation and other processes Fault protection: Equipped with infrared anti-collision sensor and emergency brake button, it has timely response and strong operation stability
4. Adaptation and guarantee
Quick change: Through modular adjustment + snap-in locking device, switching between different models and specifications can be completed within 25 minutes, adapting to multiple batches and small batch orders Working conditions adaptation: The tooling board has waterproof and antifouling characteristics, which is adapted to the cleaning working conditions of the box after foaming, and reserves a docking channel for the testing station for easy maintenance and low failure rate. Production capacity performance: The average daily transfer capacity of a single line is 200-300 units, providing stable transportation support for large-scale production of refrigerators
