Air purifier conveying line: precision transfer system for purification equipment
The air purifier conveying line is a special logistics conveying equipment designed based on the production characteristics of purification equipment. It takes “clean protection, precise transfer, and multi-specification adaptation” as the core. It adopts a modular flexible architecture and integrates anti-static conveying units and high-precision positioning modules. and segmented transmission systems provide stable transfer support for the entire process from filter element installation, fan assembly, circuit integration to finished product testing.
The main body of the wire body is made of stainless steel SUS304 and is equipped with an anti-static polyurethane conveyor belt (resistance value 10-10 Ω). The surface is smooth and free of dust adhesion, which meets the clean environment requirements of purification equipment production; the width of the conveyor track can be flexibly adjusted between 600-1200mm, with a load-bearing capacity of 500kg, and is suitable for household, commercial and industrial purifier models with different filter specifications of 300-800 mm. The key transfer link is equipped with a jack-up translation table (positioning accuracy ±0.5mm) and a servo drive speed regulation mechanism to achieve segmented beat control of 18m/min in the assembly section and 8m/min in the inspection section, accurately matching the working rhythm of different processes; Equipped with a quick replacement module, through modular adjustment and pneumatic locking device, specifications switching of different models can be completed within 10 minutes, supporting mixed-line production of multiple configuration products such as HEPA filters and activated carbon filters.
A clean air curtain interface and dust collection channel are reserved on the line body to seamlessly connect with the cleaning system of the production workshop. At the same time, it has anti-deviation and anti-collision protection functions to ensure the safety of precision parts transfer; the average daily transfer capacity of a single line reaches 400-600 units., stable structure and convenient maintenance, providing efficient, clean and accurate logistics transportation guarantee for large-scale production of air purifiers.
